BY-WM8 is a UHF dual-channel wireless microphone system for ENG, EFP, DSLR video, and can be used with two transmitters, perfect for interviews as well. The receivers and the transmitters are light and easy to use menu. It can be in one to two way (one receiver to two transmitters), or one way (one receiver to one transmitter).

Features:
Professional wireless microphone system, good helper for interview broadcast ENG EFP audio recording.
1 receiver works with 1 transmitter or 2 transmitters simultaneously.
Back electret capacitor microphone, can provide high quality and clear STEREO or MONO sound.
Adopt for PLL Synthesized Control Oscillator, effective distance 100m ~ 300m, with 48 UHF channels, can avoid signal disability effectively.
LCD display for working status, you can choose for suitable channel, voice and sound easily.
High compatibility, work well with most cameras and camcorders.
Each powered by 2 * AA batteries, can last for a long time. (Battery is not included.)
Made of ABS, with clip holder and belt clip, comes with an ABS carrying case, portable for you to carry.

Specifications:
Brand: BOYA
model: BY-WM8
quartz oscillator type: Synthesized PLL oscillator Control
Channels: 48
Carrier frequency range: - A-CH 576.4 MHz ~ 599.9 MHz
- 568.6 MHz B-CH ~ 592.1 MHz
frequency response: 60Hz-15KHz +/- 3dB operation
range: 100m ~ 300m (without obstacle)
package size: 28.3 * 23.8 * 5.3 cm / 11.1 * 9.4 * 2.1in
package Weight: 1034,5g / 36.5 oz

transmitters:
antenna: Flexible
Radio Frequency (RF) output power: 20 mW
false emission: 250 nW or less
audio input: 3.5mm Mini Jack
Audio input level: 600 mV-2000 mV
input frequency range: 20Hz-20 KHz
reference deviation: 7 KHz (-60 dBV, 1 KHz input)
power supply: 2 * AA Batteries (Not included)
Item Size: 10.3 * 6.3 * 2.1cm / 4.1 * 2.5 * 0.8in Item
Weight: 94g / 3.3 oz

- Receiver: Antenna
: Flexible
Audio Input : 3.5mm Mini Jack
Signal to Noise Ratio: 80dB Distortion : 0.8% ( -60dBV, 1KHz
Input)
headphones Output Level: 60 mW, 32 Ohm / 1 KHz
Audio Output Level : 120 mV
Power Source: 2 * AA Batteries (Not included)
Operating
Time : 6 h Item Size: 11.4 * 7.8 * 2.2 cm / 4.5 * 3.1 * 0.9in Item
Weight: 141.5g / 5.0 oz

- Lavalier Microphone Converter
: Back Electret Condenser Microphone
Polar Pattern
: Omnidirectional Frequency Range: 35Hz ~ 18KHz
Signal / Noise: 74dB SPL
Sensitivity: -30dB +/- 3dB / 0dB =
1V / Pa, 1kHz connection: 3.5mm Locking Mini Plug Length
: 1.2m / 47.2in Package List

:
2 * Transmitter with Belt Clip
1 * Receiver
2 * Microphone
1 * Stereo 3.5mm Mini plug cable 1 * XLR output cable

2 * Microphone Holder clip
2 * Windscreen
1 * Shoe Mount Adapter
1 * Carrying Case
1 * Instruction Manual (English)

Note:
Camcorders and headphones are not included.
